BL6N
No summary available
Key Features
High precision and reliability
Suitable for various industrial applications
Durable construction with long service life
Get a response within 24 hours
Product Description
额定载荷 | kg | 3/5/8/10/15/20/30/40/50/75/100 | ||
输出灵敏度 | (mV/V) | 2.0 ±0. 2 | ||
精度 | C3 | C4 | C5 | |
综合误差 | (%FS) | ±0.02 | ±0.015 | ±0.01 |
蠕变 | (%FS/30min) | ±0.0167 | ±0.0125 | ±0.01 |
温度对输出灵敏度的影响 | (%FS/10°C) | ±0.0175 | ±0.0131 | ±0.01 |
恒度对零点输出的影响 | (%FS/10°C) | ±0.02 | ±0.012 | ±0.009 |
零点输出 | (%FS) | ±2 | ||
温度补偿范围 | (°C) | -10-40 | ||
允许使用温度范围 | (°C) | -35 ~ +65 | ||
输入阻抗 | (Ω) | 406 ±6 | ||
输出阻抗 | (Ω) | 350 ±3 | ||
绝缘阻抗 | (MΩ) | ≥ 5000 ( 50VDC ) | ||
推荐激励电压 | (V) | 5 ~ 12(DC) | ||
最大激励电压 | (V) | 18(DC) | ||
安全过载范围 | (%FS) | 120 | ||
极限过载范围 | (%FS) | 150 | ||
防护等级 | IP65 | |||
电缆线规格 | mm | Ф5.0 | ||
电缆线长度 | m | 3 | ||
推荐秤台尺寸 | mm | 400x400 | ||
四角误差 | 0.02% 加载值 /100mm | |||
推荐安装扭 | N.m | 10 | ||
矩
